Expert Physical Design & Implementation
Accelerate your path from netlist to GDSII with our robust physical design methodologies. We aggressively optimize for Power, Performance, and Area (PPA) while navigating complex constraints, ensuring your chip designs are manufactured correctly the first time.
Comprehensive Implementation Flow
We handle the complete execution including synthesis, floorplanning, placement, and routing, customizing our strategy to meet the unique demands of your specific architecture.
Advanced Node Optimization
Our team specializes in advanced nodes like 14nm and 10nm, ensuring reliability through exhaustive IR/EM analysis and sign-off checks to deliver market-ready silicon excellence.
Steps to First-Pass Silicon
Our physical design methodology transforms your netlist into a manufacturing-ready GDSII. We prioritize Power, Performance, and Area (PPA) optimization to ensure your complex designs succeed at advanced nodes like 14nm and 10nm.
STEP ONE
Floorplanning & Placement
STEP TWO
CTS & Routing
STEP THREE
Sign-off & Tape-out
Strategic floorplanning and congestion-aware placement to establish a robust foundation for timing and power.Building low-skew clock trees and executing
detailed routing to maximize signal integrity and minimize crosstalk.Rigorous DRV, LVS, and IR/EM analysis to achieve timing closure and ensure a flawless tape-out.
